Appearance

Flat Flush Frame:

Yes

Control:

Sens-a-Touch Electronic Control In Glass

Oven Capacity:

4.3 Cu. Ft.

Microwave Capacity:

2.1 Cu. Ft.

One-touch Access:

Yes

Personal Cooking Assistant:

Yes

Finish:

Stainless Steel

Handle:

Stainless Steel

Comprehensive Status Display:

Yes

Panel Lock:

Yes

Performance

Microwave Power Levels:

10

Warming Drawer:

Yes

Dual Element Bake:

Lower Oven

Roast:

Yes

Variable Broil:

Lower Oven

Third Element Convection:

Lower Oven

Convection - Bake:

Yes

Convection - Roast:

Lower Oven

Convection - Broil:

Yes

Proof Mode:

Yes

Dehydrate Mode:

Yes

Sabbath Mode:

Yes

Temperature Probe:

Yes

Timed & Delay Timed Mode:

Yes

Variable 140 - 210 (Degrees F):

Yes

450 Watt Element Concealed Below Drawer:

Yes

Concealed Bake Element:

Yes

Broil:

Yes

Bake:

Yes

Genuine Convection (w/third element):

Yes

Fast Preheat Bake:

Yes

Fast Preheat Roast:

Yes

Fast Preheat Convection:

Yes

Fast Preheat Convection Bake:

Yes

Fast Preheat Convection Roast:

Yes

Warm:

Yes

Convenience

Self-Cleaning Oven(s):

Yes

Motorized Door Lock(s):

Yes

Minute Timers:

2

Child Lock-Out:

Care and Use Manual

Rack Positions:

6

Number of Racks:

3

Dual-Level Halogen Lights:

Auto / Manual

All Porcelain Broil Pan:

Yes

Ball Bearing Drawer Glides:

Yes

Concealed "Moist or Dry" Vent Control:

Yes

"ON" Light Visible With Drawer Closed:

Yes

Self-Cleanable Rack Supports:

Yes

Forward Halogen Lighting:

Yes

Independent Control of Upper and Lower Lighting:

Yes

Pyrolytic Self-Cleaning:

Yes

Smooth Glide Door Hinges:

Yes

Large Viewing Window:

Yes

Broil Element:

8 Pass

Convection Cookbook:

Included

General Information

Approximate Shipping Weight:

348 Lbs.

Approvals:

US/Canada

Technical Information

Microwave Wattage:

1100

Broil/Bake Wattage:

3600/2300

Warming Drawer Wattage:

450

Third Element Wattage:

2750

Electrical Requirements:

Dual-Rated 120/208-240 Volts, 4-Wire, 60HZ, 40 Amps

Dimensions

Overall Height:

55 3/4"

Overall Width:

26 3/4"

Overall Depth:

23 7/8"

Overall Oven Door Height:

22"

Cutout Height:

55 3/8"

Cutout Width:

25 1/2"

Cutout Depth:

24"

Cutout Floorline:

9 3/4"

Door Handle Projection:

2 7/8"

Upper Oven Interior Dimensions - Height:

9 3/4"

Upper Oven Interior Dimensions - Width:

16 3/4"

Upper Oven Interior Dimensions - Depth:

17"

Middle Oven Interior Dimensions - Height:

5"

Middle Oven Interior Dimensions - Width:

20 5/8"

Middle Oven Interior Dimensions - Depth:

19 3/4"

Lower Oven Interior Dimensions - Height:

16 1/4"

Lower Oven Interior Dimensions - Width:

22"

Lower Oven Interior Dimensions - Depth:

17 1/2"

Custom Panel Dimensions - Height:

10 1/4"

Custom Panel Dimensions - Depth

23 1/2"
